Overhead crane with electromagnetic beam is a specialized crane for lifting and moving steel products, steel plates and steel pipes. This crane is constituted by girder, traveling mechanisms, lifting trolley, electric parts and electromagnet spreader. The electromagnetic suction force of this overhead crane can last 10 minutes after power off. And the shape of electromagnet spreader could be customized bases on the shape of materials to be lifted, the magnet lifter can be round disc type magnetic lifter, square-type magnetic lifter, etc.


There are 2 types of electromagnet spreader: electromagnetic chuck and electromagnetic beam. And electromagnetic beam can also be 2 kinds: non-rotating beam (vertical or parallel to main girder) and rotating beam (Upper beam or hanging beam).

1. The cab platform entrance configurations include side entry, end entry, and top entry.

2. The cab can be mounted on either the left or right end.

3. The lifting capacity includes the weight of the magnetic disk.

4. The crane's total weight excludes the magnetic disk and its accessories.

5. The electromagnetic chuck is suspended directly below the hook. It is easy to install, remove, and maintain.

6. The hoisting brake features manual release capability. In case of malfunction, it enables rapid and smooth lowering of suspended electromagnetic chucks and loads, preventing accidents.

7. The electromagnetic chuck utilizes an independent power supply via a cable reel.

8. Equipped with power-off magnetic retention to prevent load drop due to unexpected power failure.
